PlusGuard 12 Series
10AMPS
The PlusGuard 12-10A is a Voltage Protector rated at 10 Amps, prevents damages to electrical and electronic equipment from power fluctuation, especially over and under voltage levels of long duration. The 15 sec / 30 sec / 3 min delay reconnection provides protection against power-back surge commonly experienced after resumption of power in a power cut situation. Build-in MOV excess electricity for additional protection. The PlusGuard 12-10A will automatically guard your equipment against brownouts or transient spikes induced by lighting or power line failure.


W/ Outlet: Schuko socket*1pc
W/ Input: fixed German plug power cord
W/ Delay timer 15sec/30sec/3min
W/ Surge Supresssion 900 Joules
W/ RJ-45/11 port * Input/Output: 220/230/240Vac, 50/60Hz
●  Surge Suppression 900 Joules
●  Microprocessor Controlled Design
●  Absorbs Excess Electricity through MOVs
●  LED Indicators Provide Status Information
●  High voltage and low voltage cut-off protection
●  Delay Reconnection Selector 15 sec / 30 sec / 3 min
●  Provide Modem/Phone Surge Suppression Protection




MODELPlusGuard 12-10A
INPUT
Max. Current10 Amps
Nominal Voltage220/230/240Vac
Line Low Loss180Vac
Line Low Comeback190Vac
Line High Loss265Vac
Line High Comeback260Vac
Frequency50/60Hz (Auto-sensing)
Spike Protection900 Joules
ConnectorGerman plug
OUTPUT
Nominal Voltage220/230/240Vac
Frequency50Hz or 60Hz
Delay Timer15 sec / 30 sec / 3 min
ConnectorSchuko socket
INDICATOR
LED3 LEDs
ENVIRONMENT
Operating Temperature0°C-40°C (32°F-104°F)
Humidity0-95% (Non-condensing)
Acousitc Noise<40dB at 1M
PHYSICAL
Dimension120*60*90mm
Net Weight150g
*Product specifications are subject to change without further notice.
